신제품
-
다양한 산업 애플리케이션을 위한 써모웰이 용접된 미터법 RTD/TC 온도계
| FLEX 선택 |
기술적 우수성 |
단순성 |
Fundamental 선택
기본적인 측정 요구사항 충족
|
기술적 우수성
|
단순성
|
|
|
기술적 우수성
|
단순성
|
Extended 선택
혁신적인 기술로 프로세스 최적화
|
기술적 우수성
|
단순성
|
Xpert 선택
가장 까다로운 어플리케이션 요구사항 충족
|
기술적 우수성
|
단순성
|
-
Characteristic / Application
US style
modular temperature assembly
for heavy duty applications
suitable for hazardous areas
with neck
to use with thermowell
backlit display
-
Thermowell / protection tube
-
Insert / probe
mineral insulated (MI), flexible
-
Outer diameter protection tube / Insert
-
Max. immersion length on request
up to 30.000,00 mm (1.181,10'')
-
Material protection tube/ thermowell
-
-
Process connection
male thread:
G1/2"
NPT1/2"
NPT3/4"
M24x1.5
-
-
Operating temperature range
Type K:
-40 °C ...800 °C
(-40 °F ...1.472 °F)
Type J:
-40 °C ...750 °C
(-40 °F ...1.382 °F)
-
Max. process pressure (static)
up to 20 °C: 480 bar (6.962 psi)
-
Accuracy
class 1 acc. to IEC 60584
class 2 acc. to IEC 60584
-
Response time
depending on configuration
t50 = 3 s
t90 = 7 s
-
Integration head transmitter
yes (4 … 20 mA; HART; PROFIBUS PA; FOUNDATION FIELDBUS)
-
Ex - approvals
ATEX II
ATEX Eex
explosion proof
-
63 설명서
-
Thermocouple assembly with HART®-, FOUNDATION Fieldbus™- or PROFIBUS® PA
field transmitter
|
EN
|
KO
|
|
|
01/04/2009
|
|
|
|
|
01/08/2002
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
01/04/2009
|
|
파일 크기:
|
1 MB
|
|
파일 이름:
|
TI267ten_0409.pdf
|
-
Temperature field transmitter
HART® communication
|
EN
|
KO
|
|
|
26/01/2024
|
|
|
|
|
23/11/2023
|
|
|
|
|
30/04/2021
|
|
|
|
|
16/10/2017
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
26/01/2024
|
|
파일 크기:
|
4.4 MB
|
|
파일 이름:
|
BA01801TEN_0424-00.pdf
|
-
Dual-input temperature field transmitter with FOUNDATION Fieldbus™
protocol
|
EN
|
KO
|
|
|
30/09/2023
|
|
|
|
|
26/01/2015
|
|
|
|
|
11/10/2012
|
|
|
|
|
01/12/2010
|
|
|
|
|
28/11/2006
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
30/09/2023
|
|
파일 크기:
|
4.4 MB
|
|
파일 이름:
|
BA00224REN_1623-00.pdf
|
-
Dual-input temperature transmitter with PROFIBUS<sup>®</sup>
PA protocol
|
EN
|
KO
|
|
|
30/09/2023
|
|
|
|
|
20/09/2012
|
|
|
|
|
15/06/2011
|
|
|
|
|
01/12/2009
|
|
|
|
|
01/02/2009
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
30/09/2023
|
|
파일 크기:
|
4 MB
|
|
파일 이름:
|
BA00275REN_0323-00.pdf
|
-
|
EN
|
KO
|
|
|
15/04/2024
|
|
|
|
|
20/09/2023
|
|
|
|
|
21/08/2017
|
|
|
|
|
01/01/2010
|
|
|
|
|
15/03/2007
|
|
|
|
|
언어:
|
한국어
|
|
버전:
|
15/04/2024
|
|
파일 크기:
|
3.5 MB
|
|
파일 이름:
|
KA00250RKO_0424-00.pdf
|
-
FOUNDATION Fieldbus™ 프로토콜을 지원하는 이중 입력 온도 필드 트랜스미터
|
EN
|
KO
|
|
|
20/09/2023
|
|
|
|
|
01/11/2010
|
|
|
|
|
20/10/2006
|
|
|
|
|
30/01/2006
|
|
|
|
|
언어:
|
한국어
|
|
버전:
|
20/09/2023
|
|
파일 크기:
|
2.9 MB
|
|
파일 이름:
|
KA00189RKO_1523-00.pdf
|
-
온도 필드 트랜스미터
PROFIBUS® PA 프로토콜
|
EN
|
KO
|
|
|
20/09/2023
|
|
|
|
|
17/04/2018
|
|
|
|
|
01/12/2009
|
|
|
|
|
01/03/2009
|
|
|
|
|
언어:
|
한국어
|
|
버전:
|
20/09/2023
|
|
파일 크기:
|
3 MB
|
|
파일 이름:
|
KA00276RKO_1423-00.pdf
|
-
Omnigrad S RTD and TC assembly TMT162R, TMT162C / TMT142R,
TMT142C
Safety instructions
ATEX II3G
|
EN
|
KO
|
|
|
01/08/2010
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
01/08/2010
|
|
파일 크기:
|
724.1 KB
|
|
파일 이름:
|
XA00101ta3_1310.pdf
|
-
Safety instructions ATEX II1G or II 1/2G
Compact RTD and TC Thermometer
TMT162R, TMT162C
|
언어:
|
영어
|
|
버전:
|
16/09/2005
|
|
파일 크기:
|
961.9 KB
|
|
파일 이름:
|
XA009Ten.pdf
|
-
TMT162R, TMT162C
ATEX: Ex d IIC T6…T1 Ga/Gb
Ex tb IIIC T85 °C...T450 °C Da/Db
Safety Instructions
Temperature field transmitter, ATEX Safety instructions
|
EN
|
KO
|
|
|
21/05/2015
|
|
|
|
|
01/05/2009
|
|
|
|
|
16/09/2005
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
21/05/2015
|
|
파일 크기:
|
1.1 MB
|
|
파일 이름:
|
XA00006TA3_1314.pdf
|
60 spare parts & accessories
60 spare parts & accessories
60 spare parts & accessories
-
O-Ring 88x3 HNBR 70o Shore PTFE
-
Cover latch spares kit field housing
-
Display holder kit (3 pieces)
-
-
Fieldbus connector PA M20;M12; L150
-
-
-
-
Mounting bracket st. steel wall/2" tube
-
Cable gland NPT1/2, 2xd5 cables
-
M20x1.5 cable gland, 2xD0.5 cables
-
Mounting bracket 2"tube stainless steel
-
Adapter M20x1.5 exter./M24x1.5 intern.VA
-
Cable gland NPT1/2, D4.5-8.5 IP68
-
O-Ring 18.77x1.78 HNBR 70o Shore PTFE
-
Blind plug M20x1.5 EEx-d+O-ring Alu
-
Blind plug M20x1.5 Ex-d+O-ring V4A
-
Blind plug G1/2" Ex-d+O-ring Alu
-
Blind plug G1/2" Ex-d+O-ring V4A
-
Blanks (blind) NPT1/2 V4A
-
Blanks (blind) NPT1/2, 3.1655.53
