Function
Steam and water balancing for industrial energy management
Calculations
heat quantity heat quantity difference
Communication
1 x RS232 2 x RS485 PROFIBUS DP M-Bus Modbus RTU
Loop power supply
90...250V AC 50/60 Hz 20...28V AC 50/60 Hz 20...36V DC
Input
2...6x RTD 2...8x I 2...8x PFM 2...8x Impulse (aktive) 2...8x Impulse (passive)
Output
3...9x transmitter power supply
Dimensions (WxHxD)
135 x 108 x 114 mm (5.32" x 4.25" x 4.49")
Operation
Soft keys RS232 and operation software ReadWin 2000
Display
Dot-Matrix LCD, backlit, colour change in case of alarm event
Software functions
International calculation standards for steam and water
29 설명서
RMS621
Technical Information
Steam and Heat Computer for Industrial Energy Calculation of Steam and Water
EN
KO
불가리아어 독일어 스페인어 에스토니아어 French 이탈리아어 일본어 폴란드어 러시아어 중국어
23/11/2017
13/02/2017
01/09/2010
28/01/2008
09/03/2005
언어:
영어
버전:
23/11/2017
파일 크기:
908.4 KB
파일 이름:
TI00092REN_1517.pdf
V3.03.01 이상 PROFINET 모듈("PROFINET 커플러")
EN
KO
불가리아어 체코어 덴마크어 독일어 그리스어 스페인어 에스토니아어 핀란드어 French 크로아티아어 헝가리어 인도네시아어 이탈리아어 일본어 Lithuanian Latvian 네덜란드어 노르웨이어 폴란드어 포르투갈어 루마니아어 러시아어 슬로바키아어 슬로베니아어 스웨덴어 태국어 터키어 중국어
28/02/2020
언어:
한국어
버전:
28/02/2020
파일 크기:
5.8 MB
파일 이름:
BA02024RKO_0120.pdf
Operating manual Energy manager RMS621
The RMS621 energy manager for monitoring energy and flows in water and steam applications.
EN
KO
불가리아어 체코어 독일어 스페인어 French 이탈리아어 네덜란드어 폴란드어
14/02/2017
25/09/2014
22/12/2011
01/09/2010
06/09/2007
언어:
영어
버전:
14/02/2017
파일 크기:
3.4 MB
파일 이름:
BA00255REN_1617.pdf
RMx621
Operating Instructions
Appendix to the Operating Instructions M-Bus interface V3.08.00: Connecting the Energy Manager to M-Bus system (two-wire bus in acco rdance with DIN EN 1434-3)
EN
KO
체코어 독일어
01/03/2017
15/08/2011
20/01/2011
28/11/2008
20/09/2007
언어:
영어
버전:
01/03/2017
파일 크기:
259.5 KB
파일 이름:
BA00216REN_0317.pdf
Operating manual Energy manager
RMS 621 SW Version 2.0
The RMS 621 energy manager for monitoring energy and flows in water and steam applications.
EN
KO
독일어 스페인어 French 이탈리아어 폴란드어 러시아어
20/08/2004
언어:
영어
버전:
20/08/2004
파일 크기:
3.9 MB
파일 이름:
Ba127ren.pdf
Operating manual Energy manager
RMS621
> SW Version 3.0
The RMS621 energy manager for monitoring energy and flows in water and steam applications.
EN
KO
체코어 독일어 스페인어 French 이탈리아어 네덜란드어
05/08/2005
10/01/2005
언어:
영어
버전:
05/08/2005
파일 크기:
3 MB
파일 이름:
BA182ren.pdf
Zusatzbetriebsanleitung/Addition Manuals Ethernet-Anbindung
Zusatzbetriebsanleitung/Addition Manuals Ethernet-Anbindung Memo-/Eco-Graph
EN
KO
독일어
09/05/2008
05/07/2004
언어:
영어
버전:
09/05/2008
파일 크기:
155.8 KB
파일 이름:
ZBA109Ra2_0408.pdf
Operating Manuals ReadWin 2000 (GB)
Operating Manuals ReadWin 2000
EN
KO
체코어 덴마크어 독일어 스페인어 French 이탈리아어 폴란드어 스웨덴어
01/01/2010
31/10/2008
20/06/2007
25/07/2001
언어:
영어
버전:
01/01/2010
파일 크기:
6.3 MB
파일 이름:
BA137Ren_0110.pdf
V2.01.00 이상 DP 슬레이브 모듈("PROFIBUS 커플러")
EN
KO
불가리아어 체코어 덴마크어 독일어 그리스어 스페인어 에스토니아어 핀란드어 French 크로아티아어 헝가리어 인도네시아어 이탈리아어 일본어 Lithuanian Latvian 네덜란드어 노르웨이어 폴란드어 포르투갈어 루마니아어 러시아어 슬로바키아어 슬로베니아어 스웨덴어 태국어 터키어 중국어
03/02/2020
11/08/2009
29/11/2007
14/12/2006
28/09/2004
언어:
한국어
버전:
03/02/2020
파일 크기:
1.3 MB
파일 이름:
BA00154RKO_1320.pdf
Appendix to operating instructions RMx621
Energy Manager and Application Manager RMx621 with ModBus Interface V3.03.00. Connecting the Energy/Application Manager to ModBus-IDA-systems
EN
KO
독일어 핀란드어 French 이탈리아어
11/08/2009
28/11/2008
20/09/2007
05/05/2006
언어:
영어
버전:
11/08/2009
파일 크기:
449.7 KB
파일 이름:
Ba231ren_0809.pdf
60 spare parts & accessories
60 spare parts & accessories
60 spare parts & accessories
Front cover for version without display
Front cover for version with display
Housing cpl. without front, incl. 3x dummy inserts
Power supply 18-36VDC/20-28VAC
Display for units with software FSU00xA
Front board, vers. w/o display, FSU00xA for units with software FSU00xA
Display + front cover, software FSU00xA for units with software FSU00xA
Display for units with software FCSx0xA
Front board, version w/o display for units with software FCSx0xA
Display + front cover for units with software FCSx0xA
Extension board temperature (Pt100/Pt500/Pt1000)cpl.incl. connector + fixing frame
Extension board universal (PFM/pulse/analogue/loop power) cpl. incl.connector + fixing frame
Terminal plug-in 4pol.SMSTB2,5 91/92/53/
Terminal plug-in 4pol.SMSTB2,5 82/81/10/
Terminal plug-in 4pol.SMSTB2,5 83/81/110
Terminal plug-in 4pol.SMSTB2,5 104..101
Terminal plug-in 4pol.SMSTB2,5 134..131
도면 번호
주문 코드
15/17
51004066
Terminal plug-in 4pol.SMSTB2,5 1/5/6/2
Terminal plug-in 4pol.SMSTB2,5 3/7/8/4
Terminal RMx621/FML621, Input 1, RTD
Terminal RMx/FML621, Input 2, RTD
Terminal RMx/FML621, Input 2, 4-20mA
Terminal RMx/FML621, Input 1, 4-20mA
Terminal RMx/FML621 dig./open collecto
Terminal plug-in RMx/FML621 relay
PROFINET device for DIN rail
Display-/operat. keys: in offset housing for panel mounting 144x72mm. For units with software FCSx0xA. By using display on unit and display in offset simultaneous only usable together with the "new" unit display (FW: >=3.02.03)
Display-/operat. keys: in offset FSU00xA housing for panel mounting 144x72mm. For units with software FSU00xA. By using display on unit + display in offset simultaneous only usable together with "old" unit display (FW: < 3.02.03)
PROFIBUS DP slave module from software >=V2.01.00 for DIN rail
Set, 10x fixing lever housing
Housing Field, R4 182x180x165, 5xM20, PC
