Turbimax W CUS41

이 제품은 더 이상 제공되지 않습니다.

구모델 / 신모델 섹션에서 신모델을 확인하거나 Endress+Hauser로 문의하시기 바랍니다.

특징 및 사양

뒤로

Details

  • 측정 원리

    Single beam scattered light

  • Application

    Industrial water, solid content measurement

  • Characteristic

    optical sensor for turbidity measurement acc. DIN EN ISO 7027.

  • Measurement range

    0,00 - 9999FNU0,00 - 9999ppm0,0 - 300g/L0,0 - 200,0%

  • Measuring principle

    Optical turbidity measurement following the 90° scattered light method in the near infrared (880nm).

  • Design

    Infrared sender with two receiver for low and higher range as wll as a reference receiver. Chamfered sensor head to optimize the self cleaning and additional with wiper to remove micro bubbles from the optical window.

  • Material

    Sensor shaft : PVC / PPS GF40Optical window : saphirecable TPEO

  • Dimension

    Diameter : 40mm
    1.56 inchLength : 191mm
    7.44 inch

  • Process temperature

    max. 50°C
    122°F

  • Process pressure

    max. 6bar
    87psi

  • Temperature sensor

    Integrated NTC-temperature sensor

  • Connection

    Fixed cable

  • Ingres protection

    IP68

  • Additional certifications

    Calibration certification
