신제품
-
Transmitter for non-contact point level detection and bulk flow monitoring
| FLEX 선택 |
기술적 우수성 |
단순성 |
Fundamental 선택
기본적인 측정 요구사항 충족
|
기술적 우수성
|
단순성
|
|
|
기술적 우수성
|
단순성
|
Extended 선택
혁신적인 기술로 프로세스 최적화
|
기술적 우수성
|
단순성
|
Xpert 선택
가장 까다로운 어플리케이션 요구사항 충족
|
기술적 우수성
|
단순성
|
-
Characteristic / Application
Contactless measurement
Microwave transmitter
-
-
Ambient temperature
-20 °C ... 70 °C
(-4°F ... 158°F)
-
Process temperature
Waves emitted from outside (non-contact): any
Waves emitted within installation (contact):
-20 °C ... 70 °C
(-4°F ... 158 °F)
-
Process pressure / max. overpressure limit
Waves emitted from outside (contactless): any
Waves emitted within installation (contact):
0.8 bar abs ... 4.8 bar abs (12 psi ... 70 psi)
-
-
Main wetted parts
Within installation: Aluminium, PTFE
Or: non-contact
-
Process connection
1-1/2" G + NPT
or with waves emitted from outside / mounting from outside, walls of container must not be made of metal
-
Process connection hygienic
With waves emitted from outside
-
Communication
Transmitter: Relays, DPDT
-
-
-
Components
Reciever: FDR50
Transmitter: FTR325
-
-
Application limits
When waves are emitted from outside (non-contact)
Solid weight: <10g/l
10 설명서
-
Technical Information Soliwave FQR50 / FDR50
Non-contact, non-wearing detection of bulk solids of all kinds
|
EN
|
KO
|
|
|
19/08/2016
|
|
|
|
|
11/08/2014
|
|
|
|
|
28/07/2011
|
|
|
|
|
05/03/2009
|
|
|
|
|
04/08/2008
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
19/08/2016
|
|
파일 크기:
|
1.2 MB
|
|
파일 이름:
|
TI00378FEN_1516.pdf
|
-
Operating instructions Soliwave FQR 50 / FDR 50
Microwave barrier
|
EN
|
KO
|
|
|
19/08/2016
|
|
|
|
|
11/08/2014
|
|
|
|
|
28/07/2011
|
|
|
|
|
05/03/2009
|
|
|
|
|
04/08/2008
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
19/08/2016
|
|
파일 크기:
|
1.6 MB
|
|
파일 이름:
|
KA00206FA6_1516.pdf
|
-
Approval No.: DMT 03 ATEX E 053
ATEX II 1/2 D IP66 T 102°C
|
EN
|
KO
|
|
|
01/11/2007
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
01/11/2007
|
|
파일 크기:
|
484.8 KB
|
|
파일 이름:
|
XA223FA3_1107.pdf
|
-
Approval No.: BVS 07 ATEX E 148 X
ATEX II 1/2 G
Protection: Ex ia IIC T4
ATEX II 1/2 D Ex iaD 20/21 IP66 T 98°C
|
EN
|
KO
|
|
|
07/09/2016
|
|
|
|
|
29/07/2011
|
|
|
|
|
01/11/2007
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
07/09/2016
|
|
파일 크기:
|
2.6 MB
|
|
파일 이름:
|
XA00219FA3_1416.pdf
|
-
Soliwave M FQR50, FDR50
Nivotester FTR325
Approval No.: IECEx BVS 09.0007X
Zone 0/1 Ex ia IIC T4,
Ex iaD 20/21 IP66 T98°C
[Zone 0] [Ex ia] IIC,
[Ex iaD]
|
EN
|
KO
|
|
|
19/08/2016
|
|
|
|
|
29/07/2011
|
|
|
|
|
05/03/2009
|
|
|
|
|
01/02/2009
|
|
|
|
|
언어:
|
영어
|
|
버전:
|
19/08/2016
|
|
파일 크기:
|
283.5 KB
|
|
파일 이름:
|
XA00484FEN_1416.pdf
|
-
Catálogo Medición y Detección de nivel
Gama de productos para aplicaciones con líquidos y sólidos
|
언어:
|
스페인어
|
|
버전:
|
01/06/2022
|
|
파일 크기:
|
7.2 MB
|
|
파일 이름:
|
FA00001Fes Catalogo Nivel_24.22.pdf
|
-
Prozessautomatisierung, die Gold wert ist
Memosens pH-Sensoren verbessern Prozesse bei Agnico Eagle
|
언어:
|
독일어
|
|
버전:
|
01/07/2016
|
|
파일 크기:
|
1.5 MB
|
|
파일 이름:
|
CS01496CDE_0116_Agnico Eagle Goldmine.pdf
|
-
L’automatisation des process vaut son pesant d’or
Memosens Les sondes de pH améliorent les process chez Agnico Eagle
|
언어:
|
French
|
|
버전:
|
01/07/2016
|
|
파일 크기:
|
673.1 KB
|
|
파일 이름:
|
CS01496CFR-0216-Agnico Eagle.pdf
|
-
Process automation worth its weight in gold
Memosens pH sensors improve processes at Agnico Eagle
|
언어:
|
영어
|
|
버전:
|
01/07/2016
|
|
파일 크기:
|
1.5 MB
|
|
파일 이름:
|
CS01496CEN_0116_Agnico Eagle goldmine.pdf
|
-
Product family: Nivotester, Soliwave M
Product root: FDR50-, FQR50-, FTR325-
Approval agency: BVS
|
언어:
|
영어
|
|
버전:
|
23/08/2016
|
|
파일 크기:
|
2.8 MB
|
|
파일 이름:
|
BVS_07_ATEX_E_148_X_N1 (DE).zip
|
60 spare parts & accessories
60 spare parts & accessories
60 spare parts & accessories
-
Electronic insert Q-A, FQR50
-
Electronic insert Q-B, FQR50
-
Electronic insert Q-C, FQR50
-
Electronic insert Q-D, FQR50
-
Sightglass disc DN50, 25bar, 200oC
-
Sightglass disc DN50, 10bar, 200oC
-
Sightglass disc DN80, 200oC
-
Sightglass disc DN50, 200oC
-
Sightglass disc DN50, 6bar, 200oC
-
Sightglass disc DN80, 25bar, 200oC
-
Sightglass disc DN80, 10bar, 200oC
-
Sightglass disc DN80, 6bar, 200oC
-
Sightglass disc DN100, 25bar, 200oC
-
Sightglass disc DN100, 10bar, 200oC
-
Sightglass disc DN100, 200oC
-
Sightglass disc DN100, 6bar, 200oC
-
Flange DN40 PN6, Rp1-1/2, Alu
-
Flange DN40 PN40, Rp1-1/2, 316Ti
-
Flange DN40 PN40, Rp1-1/2, 316Ti, 3.1
-
Flange DN50 PN16, Rp1-1/2, 316Ti
-
Flange DN50 PN16, Rp1-1/2, 316Ti, 3.1
-
Flange DN100 PN16, Rp1-1/2, 316Ti
-
Flange DN100 PN16, Rp1-1/2, 316Ti, 3.1
-
Flange 1-1/2" 150lbs, NPT1-1/2, Alu
-
Flange 1-1/2" Cl.150, NPT1-1/2, 316Ti
-
Flange 1-1/2" Cl.150,NPT1-1/2,316Ti,3.1
-
Flange NPS 2" Cl.150, NPT1-1/2, 316Ti
-
Flange 2" Cl.150, NPT1-1/2,316Ti, 3.1
-
Flange NPS 4" CL.150, NPT1-1/2, 316Ti
-
Flange 4" Cl.150, NPT1-1/2,316Ti, 3.1
-
Threaded fitting DN50, 6bar, 200oC
-
Threaded fitting DN80, 6bar, 200oC
-
Threaded fitting DN100, 6bar, 200oC
-
Welded fitting DN50, 200oC
-
Welded fitting DN50, 10bar, 200oC
-
Welded fitting DN80, 200oC
-
Welded fitting DN80, 10bar, 200oC
-
Welded fitting DN100, 200oC
-
Welded fitting DN100, 10bar, 200oC
-
Flanged fittingDIN/EN DN50,25bar200oC
-
Flanged fittingDIN/EN DN80,25bar200oC
-
Flanged fit.DIN/EN DN100,25bar200oC
-
HT-adapter R1-1/2 + Rp1-1/2, 316Ti
-
HT-adapter NPT1-1/2, 316Ti
-
Extension 225mm, HT-adapter R1-1/2 +
-
Extension 325mm, HT-adapter R1-1/2 +
-
Extension 525mm, HT-adapter R1-1/2 +
-
Extension 225mm, HT-Adapter NPT1-1/2
-
Extension 325mm, HT-adapter NPT1-1/2
-
Extension 525mm, HT-adapter NPT1-1/2
-
Mounting bracket FQR5x/FDR5x, Aluminium
-
Mounting bracket FQR5x/FDR5x, Plastics
