8 채널 트랜스미터
Liquiline CM448

8 채널 트랜스미터
Liquiline CM448 ©Endress+Hauser

Liquiline CM448는 모든 어플리케이션의 프로세스 모니터링과 제어를 위한 디지털 멀티파라미터 트랜스미터입니다.

하트비트 기술(Heartbeat Technology)은 프로세스 최적화를 위한 진단, 검증 및 모니터링 기능을 제공합니다. ©Endress+Hauser

하트비트 기술(Heartbeat Technology)은 프로세스 최적화를 위한 진단, 검증 및 모니터링 기능을 제공합니다.

모듈식으로 설계된 트랜스미터는 언제든지 프로세스에 맞춘 모듈 추가가 가능합니다. ©Endress+Hauser

모듈식으로 설계된 트랜스미터는 언제든지 프로세스에 맞춘 모듈 추가가 가능합니다.

비디오를 통해 Memosens가 프로세스의 관리와 유지보수를 최적화하는 법을 확인해 보세요.

모든 산업을 위한 유연한 멀티파라미터 현장 계기

Liquiline CM448은 모든 어플리케이션의 프로세스 모니터링과 제어를 위한 디지털 멀티파라미터 트랜스미터로, 8채널 컨트롤러가 완벽한 시스템 통합과 간단한 작동을 지원해 시간과 비용을 절약하고 예비 부품 재고를 최소화할 수 있습니다. 또한 측정 작업에 맞춰 컨트롤러를 조정하고 필요에 따라 1~8개의 센서를 연결할 수 있습니다. Liquiline CM448은 단순성에서 프로세스 안전성에 이르기까지 최고의 트랜스미터 플랫폼이 제공하는 모든 장점을 갖추고 있습니다.

  • 장점

    • 단순성:
      한 컨트롤러를 모든 파라미터와 어플리케이션에서 사용, 직관적인 사용자 인터페이스, 자동 센서 인식, 사전 교정된 Memosens 센서를 통한 핫 플러그 앤 플레이 지원.

    • 완전한 패키지:
      한 계기에서 8채널을 지원해 모든 측정 작업에서 최고의 유연성을 제공합니다.

    • 완벽한 시스템 통합:
      모든 분산 제어 시스템(DCS)에 적합한 고유한 통신 표준 포트폴리오.

    • 간단하고 안전한 시운전:
      SD 카드에 구성을 저장해 중복 설치에서 신속한 설정이...

  • 적용 분야

    Liquiline CM448 멀티파라미터 트랜스미터는 다음과 같은 산업과 설비를 포함해 비 방폭 지역의 모든 어플리케이션에 적합합니다.

    • 식음료

    • 생명과학

    • 발전 및 에너지

    • 상하수 처리

    • 화학

    Liquiline CM448은 다음과 같은 모든 일반적인 통신 프로토콜과 인터페이스를 지원합니다.

    • 0/4...20 mA

    • HART

    • PROFIBUS DP

    • Modbus TCP / Modbus RS485

    • EtherNet/IP

    • Webserver

Details

  • 측정 원리

    Single beam scattered light

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Design

    8x Memosens input, 2 to 8x current output,
    Alarmrelay, 2x relay, SD card for software update and copy & paste of setup

  • Material

    Housing base: PC-FR
    Housing seal EPDM

  • Dimension

    237 x 194 x 162 mm
    9.33 x 7.64 x 6.38 inch

  • Process temperature

    -20 to 55 °C (0 to 130 °F)

  • Ingres protection

    IP66 / IP67

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Additional certifications

    EAC, cCSAus

  • 측정 원리

    Free chlorine

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Design

    8x Memosens input, 2 to 8x current output,
    Alarmrelay, 2x relay, SD card for software update and copy & paste of setup

  • Material

    Housing base: PC-FR
    Housing seal EPDM

  • Dimension

    237 x 194 x 162 mm
    9.33 x 7.64 x 6.38 inch

  • Process temperature

    -20 to 55 °C (0 to 130 °F)

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Additional certifications

    EAC, cCSAus

  • 측정 원리

    Glass electrode

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Design

    8x Memosens input, 2 to 8x current output,
    Alarmrelay, 2x relay, SD card for software update and copy & paste of setup

  • Material

    Housing base: PC-FR
    Housing seal EPDM

  • Dimension

    237 x 194 x 162 mm
    9.33 x 7.64 x 6.38 inch

  • Ingres protection

    IP66 / IP67

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Additional certifications

    EAC, cCSAus

  • 측정 원리

    Glass electrode

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Design

    8x Memosens input, 2 to 8x current output,
    Alarmrelay, 2x relay, SD card for software update and copy & paste of setup

  • Material

    Housing base: PC-FR
    Housing seal EPDM

  • Dimension

    237 x 194 x 162 mm
    9.33 x 7.64 x 6.38 inch

  • Process temperature

    -20 to 55 °C (0 to 130 °F)

  • Ingres protection

    IP66 / IP67

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Additional certifications

    EAC, cCSAus

  • 측정 원리

    Potentiometric / ISE

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Process temperature

    -20 to 55 °C (0 to 130 °F)

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • 측정 원리

    Sensor ORP / Redox

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Design

    8x Memosens input, 2 to 8x current output,
    Alarmrelay, 2x relay, SD card for software update and copy & paste of setup

  • Material

    Housing base: PC-FR
    Housing seal EPDM

  • Dimension

    237 x 194 x 162 mm
    9.33 x 7.64 x 6.38 inch

  • Process temperature

    -20 to 55 °C (0 to 130 °F)

  • Ingres protection

    IP66 / IP67

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Additional certifications

    EAC, cCSAus

  • 측정 원리

    Sensor Oxygen

  • Application

    Modular 4 wire controller
    Multichannel: 1 to 8 digital channels for Memosens protocol
    Multiparameter: pH, redox, ISFET, conductivity inductive and conductive, dissolved oxygen, nitrate and turbidity
    8 sensors connectable in any combination
    Functionality modular extendable at any time
    Plug and play for modules and sensors

  • Characteristic

    Robust plastic housing
    All non-ex applications

  • Design

    8x Memosens input, 2 to 8x current output,
    Alarmrelay, 2x relay, SD card for software update and copy & paste of setup

  • Material

    Housing base: PC-FR
    Housing seal EPDM

  • Dimension

    237 x 194 x 162 mm
    9.33 x 7.64 x 6.38 inch

  • Process temperature

    -20 to 55 °C (0 to 130 °F)

  • Input

    1 to 8x Memosens digital input
    2x 0/4 to 20mA Input optional
    2 to 4x Digital input optional

  • Output

    2 to 8x 0/4 to 20 mA current outputs, alarmrelay
    4x relay, ProfibusDP, Modbus RS485, Modbus TCP, Ethernet

  • Additional certifications

    EAC, cCSAus
