신제품
-
생명 과학 및 식음료 산업을 위한 위생 어셈블리
| FLEX 선택 |
기술적 우수성 |
단순성 |
Fundamental 선택
기본적인 측정 요구사항 충족
|
기술적 우수성
|
단순성
|
|
|
기술적 우수성
|
단순성
|
Extended 선택
혁신적인 기술로 프로세스 최적화
|
기술적 우수성
|
단순성
|
Xpert 선택
가장 까다로운 어플리케이션 요구사항 충족
|
기술적 우수성
|
단순성
|
-
Application
Process, food, pharmaceuticals
-
Installation
Fixed installation assembly
-
Characteristic
Open and closed tank, piping.
-
Design
- Hygienic assembly with corresponding process connections - 120 mm electrodes - optional with protection guard - optional with leakage control
-
Material
Holder: stainless steel sealing : different materials available (FDA conform)
-
Dimension
10 - 86 mm
(0.39 - 3.47 inch)
-
-
-
Connection
DN25 thread adapter nut, Triclamp, Varivent, APV, dairy fitting DN50, Neumo Bi°Control.
-
Certificates, declarations and approvals
- Material certification 3.1.B EN 10204- 3A / EHEDG (steam sterilisability + cleanability)- Surface roughness Ra<0,8 (0,4).
-
Application
Process, Food, Pharmaceuticals
-
Installation
Fixed installation assembly
-
Characteristic
Open and closed tank, piping.
-
Design
- Hygienic holder with corresponding process connections.- 120mm electrodes- Optional with protection guard- Optional with leakage control
-
Material
Holder : Stainless steelSealing : different materials available (FDA conformable)
-
-
-
-
Connection
DN25 thread adapter nut, Triclamp, Varivent, APV, dairy fitting DN50, Neumo Bi°Control.
-
Certificates, declarations and approvals
- Material certification 3.1.B EN 10204- 3A / EHEDG (steam sterilisability + cleanability)
-
Application
Process, Food, Pharmaceuticals
-
Characteristic
Open and closed tank, piping. Fixed installation assembly
-
Design
- Hygienic holder with corresponding process connections.- Optional with protection guard- Optional with leakage control
-
Material
Holder : Stainless steelSealing : different materials available (FDA conformable)
-
Dimension
10 - 86mm
(0.39 - 3.47inch)
-
-
-
Connection
DN25 thread adapter nut, Triclamp, Varivent, APV, dairy fitting DN50, Neumo Bi°Control.
-
Certificates, declarations and approvals
- Material certification 3.1.B EN 10204- 3A / EHEDG (steam sterilisability + cleanability)- Surface roughness Ra<0,8 (0,4).
60 spare parts & accessories
60 spare parts & accessories
60 spare parts & accessories
-
Sealing set FPM CPA442, FDA listed
-
Sealing set FPM CPA442, pharma CoC cert.
-
Sealing set EPDM CPA442, FDA listed
-
Sealings EPDM CPA442, pharma CoC cert.
-
Sealing set Silicon CPA442, FDA listed
-
Kit CPA442: Union nut G11/4" brass
-
Kit CPA442: Union nut G11/4", 316Ti
-
Kit CPA442: Protection cover POM/316Ti
-
Welding stud CPA442, straight, 50mm
-
Welding stud CPA442, oblique, 50/60mm
-
Welding stud CPA442, straight, 30mm
-
Welding stud CPA442, oblique, 30/40mm
-
Dummy plug 1.4435, G 1 1/4" internal
-
Dummy plug 1.4435, G 1 1/4" internal
