Sludge level CUM750

Product picture of: Sludge level CUM750

이 제품은 더 이상 제공되지 않습니다.

구모델 / 신모델 섹션에서 신모델을 확인하거나 Endress+Hauser로 문의하시기 바랍니다.

특징 및 사양

뒤로

Details

  • 측정 원리

    Ultrasonic sensor

  • 측정 원리

    Ultrasonic sensor

  • Application

    Primary clarifier, sludge thickener, setting basin after flocculant dosage, sludge height in contact sludge, static separation process.

  • Installation

    open tanks

  • Characteristic

    Ultrasonic measuring system for separation zone and sludge level detection.

  • Measurement range

    Sludge level : 0,3m - 100m

  • Measuring principle

    Ultrasonic measurement with a frequency of 657kHz and a wave length of 0,2cm.

  • Design

    Multichannel-transmitter for up to 4 ultrasonic sensors CUS70 with backlight multifunctional display for graphical and numerical display.

  • Material

    Housing : PolycarbonateWindow : Plexiglas

  • Dimension

    265x227x160mm

  • Ex certification

    No

  • Ingres protection

    IP565

  • Input

    Level measurement

  • Output

    - 0/4 - 20mA for level measurement.- up to 4 outputs.
